Color
-
ECP-60NET/PMK11
Pearl White -
ECP-60NET/PMK12
Pearl Vanilla
PEARL MASK II
Spec
Porous ceramics / Glazed
Field material ECP-60NET/PMK11~PMK12
| Size/pc | 60.6x60.6mm |
|---|---|
| Size/sht (Actual) | 303x303mm |
| Thickness | 5.5mm, 8.5mm Mix |
| Joint | Closed joint |
| Quantity/sqm | 11.3shts |
| Quantity/ctn | 11shts |
| Weight/ctn | 11.5kg |
-
Dimension of sheet -
Dimension of piece
(6mm, 8.5mm mixed) -
Mounting : Back net
Corner material ECP-60N/90-14/PMK11~PMK12
| Size/pc | (60.6+60.6)x60.6mm |
|---|---|
| Size/sht (Actual) | (60.6+60.6)x303mm |
| Thickness | 5.5mm |
| Joint | Closed joint |
| Quantity/m | 3.4shts |
| Quantity/ctn | 11shts |
| Weight/ctn | 4.5kg |
-
Dimension of sheet -
Installation for corner
(External) -
Layout pattern
Link to more information
Installation Tools:
Square notch trowel 3mm
Note:
This series has a direction to apply. Please follow the application pattern.
Calculation
You can calculate necessary cartons per area. Please input square meters or square feet, then you can get approximate number of cartons.
✽ For series with multiple shapes, please select model number before input area.
=0ctn
